IMPORTANT NOTES:
1. I am an Olympus Malaysia employee.
2. This is a user experience based review, based on my personal opinion which can be subjective.
3. All images were shot in RAW and converted directly to JPEG (High Quality) via Olympus Viewer 3
4. General camera settings, Noise Filter = OFF, Contrast/Saturation/sharpness = 0, White Balance = Auto (with an option maintain warm color = OFF), Gradation = Normal
5. Minimal post-processing applied to the images, with slight brightness/contrast balance tweak. All images were almost as good as straight out of camera, with minimal cropping for better presentation.
Note: E-M1 Mark II Blog Extension (click) is now published, covering 50MP High Res Shot, Electronic Shutter improvements, Cinema 4K shooting and upgrades of camera features.
Olympus OM-D E-M1 Mark II (which was originally announced as "in development phase" in Photokina 2016) is the much anticipated successor for the 2013 flagship E-M1.
I have had the chance to shoot with the E-M1 Mark II extensively over 3 days in various real life conditions covering as many tests as I can. It is difficult to post all my findings and results in one single blog entry, so for this particular blog review I shall be focusing on the most important points of my review. There are just too many things to say about this E-M1 Mark II, and so many sample photographs I want to share here. I shall cover the other parts which are not mentioned here in my coming review extension.
The new Olympus OM-D E-M1 Mark II is an ambitious camera on specifications, surpassing the original E-M1 by quite a far margin in all aspects and also addressed it's many shortcomings.
The key specifications of Olympus OM-D E-M1 Mark II are highlighted as follows:
1) NEW AUTOFOCUS SYSTEM
The AF system has undergone a major improvement, especially when it comes to continuous AF. Olympus used 121 full cross phase-detect AF points alongside the contrast detect AF system for much better continuous subject tracking. The E-M1 Mark II is able to shoot all images in RAW at the sequential burst mode of 60 frames per second (single-AF, electronic shutter), 18 frames per second (Continuous-AF, electronic shutter), 15 frames per second (Single-AF, mechanical shutter) and 10 frames per second (continuous AF, mechanical shutter). The buffer limit has been increased to 77 RAW files before the camera slows down in operation. The image sensor readout rate AF processing speed in the camera is claimed to have been dramatically increased to eliminate jello/image stretching effect when shooting high speed in electronic shutter mode. The behavior of the Continuous AF can be further fine-tuned for tight and loose framing to suit different subject moving conditions. Furthermore, the new AF system includes the Pro Capture Mode that starts to capture images immediately as the shutter button is half-pressed and storing 14 full RAW images before the shutter button is fully pressed, minimizing the chance of missing the actual moments.
2) 5-AXIS IMAGE STABILIZATION IMPROVEMENTS
The built in camera 5-Axis Image Stabilization system is also improved, allowing 5.5 shutter speed steps of compensation with any lens attached on the E-M1 Mark II. If you use the new Olympus M.Zuiko 12-100mm F4 PRO lens, you can get up to 6.5 steps of shutter speed compensation. This benefits both stills and movie recording.
3) NEW 20MP IMAGE SENSOR WITH NEW TRUEPIC 8 IMAGE PROCESSOR
A new 20MP Live MOS image sensor is used in the E-M1 Mark II, and Olympus claims this is not the same as the one used in the Olympus PEN-F body. The E-M1 Mark II's 20MP image sensor also has the phase detect AF points built onto it, and has much faster data readout rate to enable 4K video recording, thus it should not be the same as the one used in PEN-F. To accompany the new image sensor and 4K video recording capabilities, a new processing engine was introduced: the Truepic 8. According to the detailed specifications, the new Truepic 8 chip has double Quad Core system: 4 CPU cores and 4 image processing cores.
4) OTHER IMPORTANT FEATURES/IMPROVEMENTS
- full weather-sealing (freezeproof down to -10 degrees Celcius, dustproof and splashproof)
- improved Electronic Viewfinder with super short 6ms delay and 120fps refresh rate
- larger battery capacity
- dual SD card slots
- improved video capabilities, now with 4K recording
- all other original Olympus specific features such as live bulb/time/composite, art filters, highlight & shadow control etc are also included in E-M1 Mark II
For full specifications please visit the official Olympus website here (click).
Let's jump right into the review.
HOW MUCH IMPROVEMENT IN THE IMAGE STABILIZATION?
With the original Olympus OM-D E-M1, I could hand-hold and shoot confidently at half a second, or even stretching to a low 1 second slow shutter speed using a wide angle lens (7-14mm F2.8 PRO). Then came along the amazing M.Zuiko 300mm F4 IS PRO lens, I can handhold at 300mm at about 1/10sec shutter speed, which was quite an incredible feat. When Olympus E-M1 Mark II was announced, I did not expect any surprises at all, since we all have known, tried and proven the effectiveness of the Olympus 5-Axis Image Stabilization system.
Suddenly there was the M.Zuiko 12-100mm F4 IS PRO lens, which also has the 5-Axis Sync IS (lens 2-Axis IS working in sync with the 5-Axis IS system in the body to better stabilize the camera) and should compensate to about 6.5 steps of shutter speed. The 12-100mm F4 PRO lens was designed to work optimally on the E-M1 Mark II, so I brought them out for some slow shutter speed torturing.
Prepare to be mind-blown.
I am not kidding.
Here are the results.
CONTINUOUS AUTOFOCUS PERFORMANCE
Before I dive into the Continuous AF tests, let me clarify a few important things. I am not a sports shooter and I rarely shoot moving subjects or action photography. The autofocus mode I use 90% of the time is Single-AF, and the remaining 10% is manual focus. I never had a need for Continuous AF in my photography scenarios, hence I will admit upfront that I may not be the best person to review the performance of the Continuous AF of the E-M1 Mark II. In addition to that, I have never had extensive use of high-end cameras with highly-praised AF capabilities such as Canon 1D-series, or Nikon D4/D5 series, and I have not even used the latest APS-C champions such as Sony A6300/6500, Canon 7D Mark II and Nikon D500. Without having prior experience in C-AF from all these important "benchmark" cameras, it is difficult for me to draw any conclusions. I strongly suggest that you seek other online reviewers who are better qualified to do more meaningful tests of the E-M1 Mark II's Continuous AF capabilities.
Nonetheless, since Olympus made such a huge deal about their AF improvements, I thought it would be too easy for me to just skip it, and I thought why not give it a try. I may not be an expert, but I believe I am also experienced enough in handling Olympus cameras to get some good results. I have tested the E-M1 Mark II in Continuous AF shooting within my own shooting capabilities, and if there are shortcomings in the results, it could probably be due to my own inexperience in such circumstances.
A few technical information about the C-AF and sequential shooting of E-M1 Mark II:
1) Rolling Shutter effect/Jello distortion due to high speed shooting is greatly minimized by having a 1/60s curtain shutter speed (the speed of scanning the entire frame) in electronic shutter mode. E-M1 had only 1/13s curtain speed.
2) There is a lens focus distance limiter built into the camera, which can be used if necessary
3) The Continuous AF behaviour can be fine-adjusted to best match the subject movement pattern (tight and loose AF lock)
4) The AF targetting area options now include the "cluster group" option, which is already available in other manufacturers' cameras
C-AF TEST 1: THE FLYING MACAW
I went to the Bird Park and it was not a productive testing ground for me. It was probably not the best idea to start shooting birds as a test for C-AF, considering my inexperience. The camera can lock focus very quickly on the moving birds, that one I can pretty much guarantee, but as the birds flew randomly at such crazy speed, my brain and hands failed to move the lens to follow the birds flight paths! They often flew out of the frame and I lost the birds, and this was my explanation of not having enough skills to execute successful Continuous AF tests. It was frustrating knowing that the camera can perform considerably well, and the failure was due to my own lacking of knowing how to fully utilize the camera. This is one area which I must emphasize, getting a powerful camera can only get you so far, without the expertise to use it, the camera is just as useless as the photographer. Give me a Canon 1DX or Nikon D5 and I would probably miss any of the flying birds too.
Out of the many, many failed attempts of me following the birds, I did get one successful one, which was during the bird show. This one I could nail it, because, let's face it, that Macaw was quite a large bird, and I knew exactly where the bird was flying too (they had 3 rounds of same tricks). I managed to nail it on the second round!
C-AF, Silent Mode, Low Sequential 18 frames per second, total 48 photos.
12-100mm PRO lens used at 100mm telephoto end, F4, 1/5000sec, ISO800
The tracking was spot on for all frames except the last 3 frames.
Tips: Click on image to enlarge
C-AF TEST 2: MARC MARQUEZ (93) VS VALENTINO ROSSI (46)
Coincidentally we had the Sepang Moto Grand Prix 2016 happening in Malaysia last weekend, and I was fortunate to grab a ticket at last minute, though the shooting position was not ideal. I have never been to any racing or motorsports events before, and I have never shot anything moving that fast before also. I have no idea about the mechanics of the race and I did not even know the important players of the game. I went to the Sepang Circuit knowing I shall shoot some crazy fast bikes in action and pray to the photography god I will be able to come home with just a handful of usable images.
My friend Robert who has been following the racing scene updated me on few important details as I was reviewing the images that I have shot. He was particularly excited when he saw the series I am displaying here, as I was tracking the number 93, Marc Marquez from Spain, with a trailing number 46, Valentino Rossi who is a legend in the motorsports world. I guess I was lucky, and that is one important factor, sometimes if luck is not on your side, no matter how much you have planned and how prepared you are, you just don't get the shots!
C-AF, Mechanical Shutter, Low Sequential 10 frames per second, total 55 photos.
300mm PRO lens, F4, 1/1600-1/2500sec, ISO200
Tracking success was about 90%. About 5 photos were noticeably out of focus, though C-AF of E-M1 Mark II did a good job at recovering focus fairly quickly.
Tips: Click on photos to enlarge
C-AF TEST 3: SKATEBOARD
This one was totally unplanned, I was walking out from a live band performance and I chanced upon
the Rakan Muda sports center, and during Sunday afternoon there were some youngsters practicing their skateboarding (unfortunately none of them were very good at it). This was a good test to show how effective the E-M1 Mark II tracks subjects moving toward the camera.
C-AF, Mechanical Shutter, Low Sequential 10 frames per second, total 50 photos.
12-100mm PRO lens, F4, 1/800-1/1250sec, ISO800
C-AF TEST 4: MAN WALKING TOWARD CAMERA
This final test I am showing here is probably the easiest for the camera to handle. It was a straightforward test of the camera's tracking of a man walking toward me. I think this is the most popularly encountered situation when C-AF is needed (outside of sports/action photography) in usual photography needs by most photographers in many situations.
C-AF, Mechanical Shutter, Low Sequential 10 frames per second, total 44 photos.
12-100mm PRO lens, F4, 1/200-500sec, ISO800
Tracking success was about 90%. About 5 photos were slightly out of focus.
PRO CAPTURE MODE
I think the introduction of Pro Capture Mode in the E-M1 Mark II is a brilliant idea, and trust me when I say this concept will be used by other manufacturers, especially cameras that can employ electronic shutter (I do not think it is physically possible wth DSLR cameras, with moving mirror mechanism). Pro Capture Mode allows full RAW images to be captured even before the shutter button is fully pressed. That means, as you half press the shutter button, the E-M1 Mark II is already starting to shoot images and record them in the buffer. As you fully press the shutter button to capture the decisive moment, you are also effectively capturing 14 frames before that shutter button was fully pressed. Ultimately, even if you have missed the moment due to slow reaction time responding to the scene, you can be assured that the Pro Capture Mode has already shot 14 images prior to that. Take note that Pro Capture Mode functions only in electronic shutter (silent mode).
There are two Pro Capture Modes:
1) Pro Capture Mode High
shooting at 60 frames per second, single-AF only,
2) Pro Capture Mode Low
shooting at 18 frames per second, Continuous-AF or Single AF
Take note that Pro Capture Mode can capture a limit of 25 frames in total only. This mode is useful to nail that one specific moment.
I think it is important for me to tell you that when Pro Capture mode is enabled, you will experience drop of frame rate in the EVF or the LCD monitor on your camera backscreen. This was due to the camera already actively capturing the images as you started to half-press the shutter button. The view on the EVF and Live View is still pretty much in real time, you do not have to worry about lag in judging the right moment to shoot but the not so smooth view may put some people off. Nonetheless, I still feel that the sheer advantage of Pro Capture Mode guaranteeing you shots even before you fully press the shutter button outweighs the slightly laggy view in EVF/LCD monitor.
PRO CAPTURE MODE HIGH TEST
I do not have fast reflexes when it comes to shooting fast objects, hence Pro Capture Mode did come in handy when dealing with the need for quick reaction. I rarely shoot birds hence it was difficult for me to predict when the bird was going to take flight. When the bird actually started to move, I pressed the shutter button and that was already too late and the bird caught in my frame was already mid-flight! However with the Pro Capture Mode, I managed to save 14 shots taken BEFORE I press the shutter button, hence I nailed the precise moment the bird was taking off. Quite a neat trick and surely shooting action will be much better now.
This image was the one that I shot when I press the shutter button fully. The 14 images before this were captured by the Pro Capture Mode High. Take note that the bird was already slightly out of focus, since at 60 frames per second, only Single-AF is used (first frame only in perfect focus). Image appeared slightly grainy becaused I used ISO6400 for these shots.
PRO CAPTURE MODE LOW TEST
I was invited by the awesome Bihzhu to catch her performance live, which happened at TPC, Bukit Kiara, at an after party for LGPA 2016. It was a golf tournament. Since I was there for the after party I did not bring along the 300mm F4 PRO lens, which was a HUGE HUGE mistake. When I arrived, little did I know the golf tournament was still going on! I could have had a solid 1 hour shooting time, but I only had 100mm longest telephoto end with me. I took this opportunity to test out the Pro Capture Mode Low. I could not shoot the first swing since that usually happened super, super far away from where the crowd is located. I could only shoot the Golf Players when they came in closer to the hole.
Now here is an interesting observation, since the hole was quite near where the spectators were standing, the photographers were NOT allowed to use their cameras (typically loud noisy DSLR) that could distract the players in concentration. There were guards on duty holding up the large signs reading (no camera no phone) when the player was about to take her shot. Thank goodness for silent shutter! And the Pro Capture Mode was using electronic shutter so I could just fire away without worries. This is one of the important reasons why Mirorrless Cameras are the future.
This was the first frame I shot when I fully pressed the shutter button. Nothing too dramatic as golf is not exactly a fast moving sports. I purposely shot this as the ball was already a little bit ahead to show much the Pro Capture Mode can recover the "missed moments". The ability to capture that few extra shots before the actual action is something I strongly believe sports shooters will seriously treasure
SINGLE AUTOFOCUS PERFORMANCE
I do not have any comments when it comes to Single-AF, as I do feel that the performance is similar to the E-M1 or PEN-F, and that is not a bad thing because to me the Single-AF from previous incarnations of Olympus camera is already excellent and I never had any complains in actual shooting practices. I have tested the single AF (well, I used single AF in my own shooting needs) extensively and it has never once failed me, even in extreme low light conditions.
I think having quick and accurate Single-AF is still the most important criteria, and after speaking to many photographers, the general conclusion is that Olympus does an excellent job in this area. Some other manufacturers have claimed to have superior AF or even dared to boldly say "world's fastest AF" but in practical shooting situations, what truly matters is whether the AF worked or not, it is as simple as that. There is just that confidence in using Olympus Single-AF that only those who have experienced it will understand.
In many instances, I have successfully just pointed the lens at the subject and immediately captured the image. I shall be showing a few of such instances in the following images.
GENERAL IMAGE QUALITY
I am glad to find out that the image sensor used in the E-M1 Mark II is not the same as the one used in the PEN-F, and there is a new corresponding image processing engine, the Truepic 8 to accompany the new image sensor. At this point, it is difficult to gauge exactly how much the image quality has improved because there is no RAW compatibility with third party post-processing software at this moment, and Olympus Viewer 3 basically reproduces what the camera JPEG can do. Therefore, the image quality tests are solely based on JPEG quality only in this blog entry.
I did most of my tests with the M.Zuiko 12-100mm F4 PRO lens, and I know many of you have been waiting for me to write about this lens. You will see plenty of samples taken with this lens here, but I shall do a proper, full blog review for that lens separately. I did enjoy using the 12-100mm PRO lens and I am impressed by the built in IS, lens sharpness and overall performance.
At lower ISO settings (below ISO1600), with good lighting conditions, the E-M1 Mark II produces images with excellent sharpness and beautiful true to life colors. The rendering of fine details is noticeably better than previous cameras, and I have a feeling that this was largely due to the improved image processing Truepic 8. The fine details are better shown, and the JPEG compression artifacts (that many suspected was due to the default over-sharpening of JPEG) was visibly reduced.
I did not notice any improvement in dynamic range (if there was, I would think it is negligible) but the highlights roll-off is much better handled in the E-M1 Mark II, with smoother transitions. The overall color profile is slightly different than what we have seen in Truepic 7 previously, perhaps the colors are a little less aggressive, not as "punchy" and high in contrast as previously, more neutral but still maintaining good balance and looking natural.
LOW LIGHT SHOOTING WITH HIGH ISO
One of the most popular questions about E-M1 Mark II is definitely the capabilities in low light shooting with high ISO use. The ISO range remains the same, from ISO200 (native) all the way up to ISO25,600, and Olympus did not indicate specifcally at which high ISO limit was the starting point of ISO expansion. My guess is either ISO3200 or 6400. I am sure many are curious how the new image sensor combined with the new Truepic 8 processing engine helped in managing high ISO noise and retaining details in the shots done by E-M1 Mark II.
An important point worth re-emphasizing is that we are comparing in JPEG images, though I did convert these images in Olympus Viewer 3 (which gives me the same JPEG as camera anyway). There is no third party solutions to convert the RAW files from E-M1 Mark II at this moment so please do not be unreasonable by asking me for RAW samples. Even I do not have the ability to judge how the RAW images perform under third party software. We shall leave that comment to a later stage, in the future.
I have done direct side by side comparisons shooting high ISO between the new E-M1 Mark II against the older E-M1. All exposure settings were carefully set to mitigate any inconsistencies. Focus was also done manually so there was no shifting between shots, the only variable in the comparison is the exact positioning of the camera (i put the camera on the table), but this should not be an issue since we are examining the high ISO noise pattern in this particular test.
HIGH ISO TEST - DEADPOOL COMPARISON (E-M1 VS E-M1 MARK II)
ELECTRONIC VIEWFINDER AND CAMERA LCD SCREEN
One of my few disappointments with the E-M1 Mark II, is the use of the exact same LCD touch panel as the older Olympus Micro Four Thirds camera! You cannot fully operate the menu from the touch screen, and it is still a single-touch operation. That means, you cannot do pinch to zoom (like what you can do on smartphones), which would have been really useful when previewing images. That feature is already available in most of other manufacturer's cameras with touch screen capabilities, I just wish this was implemented in Olympus' Flagship camera! Come on, how difficult is it to have a multi-touch capable LCD screen, and more icon-driven menu system for simpler touch screen operation? We live in a world of smart devices now, the camera has got to get smarter somehow.
The electronic viewfinder promises two things: much better response time at 6ms delay only, and 120fps refresh rate. Indeed the EVF was a joy to use, large enough for framing comfortably and I did not experience any eye strain shooting long hours with the E-M1 Mark II through the EVF. The black out time while shooting continuously (18 frames per second C-AF tests as shown earlier) was quite minimal and I could still effectively track my subjects visibly and clearly. My only complain, which is not a big problem and I needed some time to get used to, is the more saturated than normal EVF colors in comparison to the E-M1 (2013). The EVF on the E-M1 has more neutral, almost natural looking colors which was something I am proud to show people who are not using Olympus EVF (you should have seen how different he color profiles are at "other" manufacturers' EVF).
BATTERY LIFE
As shown in the image comparison of two batteries above (E-M1 Mark II the black one, and E-M1 using the grey one), you can tell that the much chunkier E-M1 Mark II's battery means serious business! I am so glad, after so many constant complains I have given review after review on not getting sufficient battery life out of the Olympus OM-D and PEN cameras, FINALLY they made a new battery for the new E-M1 Mark II. This is huge.
One battery charge could last me an ENTIRE day, coming home with more than 1500 shots, yet I still have about 20% battery life left! On the day I was shooting the Sepang Moto GP 2016, I came home with about 3000 shots (I used sequential shooting most of the time) before the battery flattened. It is difficult to estimate how much improvement there is over the previous E-M1, but I can confidently say the new battery lasts at least TWICE as long on the E-M1 Mark II. With the exception of the Sepang Moto GP race shooting, I never needed to reach for a second/spare battery to get me through the day.
A tiny, but useful change is that the battery now has a percentage indicator! I am sure many Olympus OM-D and PEN shooters suffer this: you do not know how much battery power if left but judging by the mysterious 2/3 bars battery indicator you thought you could get maybe 150 or more shots, but about 5 minutes later the battery started blinking red and it shuts down the next 2 minutes. With the exact percentage indicator, now that won't be an issue anymore!
4K VIDEO RECORDING
After so many requests and customer feedback, FINALLY, there is 4K video recording in E-M1 Mark II.
DISCLAIMER: Now I shall politely excuse myself from commenting on the video capabilities of the E-M1 Mark II. I am not a video shooter, and I seriously have very little experience when it comes to video. I shall leave this part of the review to the actual pros.
Nevertheless I did have a 4K video, recorded at Ultra HD (3840 × 2160) and have that uploaded to Youtube. Please understand that Youtube does some funky compression for faster loading time so please do not judge the video quality. The E-M1 Mark II can record in full Cinema 4K, but I thought it was pointless to do so since I won't be able to showcase the capabilities through Youtube.
What you can judge from this video, was that the video was shot at an incredibly challenging lighting condition, fully hand-held. The 5-Axis Image Stabilization does a great job at steadying the video, even when I was walking around to frame some of the difficult to reach musicians hiding in far corners of the stage. Also, C-AF was used, but not entirely successful all the time, falling short at areas with very low contrast (the two ladies in front, who stood in the shadows), and the C-AF in the video will somehow go to areas with much stronger/bolder contrast. Other than that, I do think the C-AF is quite reliable if not encountering such complex situations. And I know all the video shooters that I know who know their game well, will shoot in manual focus only.
